REKA PIR EL 7W-O-GR

Attribute icon gwarancja5 Attribute icon IP54 Attribute icon PIR
REKA PIR EL 7W-O-GR Kanlux
Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura REKA PIR EL 7W-O-GR - KANLUX Miniatura aranżacji REKA PIR EL 7W-O-GR Miniatura schematu REKA PIR EL 7W-O-GR

Facade luminaire REKA PIR

REKA PIR EL 7W-O-GR

Product code: 28995 logo KANLUX

The Kanlux REKA PIR is a modern architectural LED luminaire designed for mounting on building facades. Equipped with a motion and twilight sensor (operating independently), it allows for adjustable lighting time (10 seconds–10 minutes) and light intensity threshold (0–1000 lx). Thanks to adjustable diffusers, it emits light in two directions – up and down – allowing for effects ranging from narrow lines to wide cascades of light. The luminaire is ideal for illuminating exterior walls, terraces, balconies, and gazebos, especially where continuous illumination is not necessary. Thanks to the sensor, it will only turn on when it's dark and detects nearby motion, and if necessary, it can also operate in continuous mode – simply switch the appropriate on/off combination.

Product presentation
Rated voltage [V] 220-240 AC
Rated frequency [Hz] 50
Maximum power [W] 7
Luminous flux of the light fitting [lm] 340
Colour temperature [K] 4000
Colour graphite
Scroll down to the full specification
Ask a question
Go to dictionary

Do you want to maintain consistency?

See products from the same series
NEW NEW
logo KANLUX
Attribute icon gwarancja5 Attribute icon IP54 Attribute icon PIR
REKA PIR EL 7W-L-GR - KANLUX REKA PIR EL 7W-L-GR - KANLUX
Facade luminaire REKA PIR REKA PIR EL 7W-L-GR Product code: 28994

Specification

General description
Warranty [years] 5
EAN13 5905339289957
Colour graphite
Enclosure material aluminum alloy
Protective glass material Tempered glass
Weight and dimensions
Height [mm] 151
Width [mm] 119
Length [mm] 136
Weight 688g
Sales unit piece
Outer box 20
Additional features
  • 5 years Warranty under the terms of the warranty statement, available on our website
  • Beam-angle adjustment
Technical data
Rated voltage [V] 220-240 AC
Rated frequency [Hz] 50
Show more ▾
Colour graphite
Maximum power [W] 7
Integrated LED light source
Luminous flux of the light fitting [lm] 340
Lighting angle [°] max 90
Number of on/off cycles ≥20000
Service life [h] 30000
Colour temperature [K] 4000
Colour uniformity [SDCM] 6
Colour-rendering index Ra 80
Diode type LED COB
Compatible with a dimmer no
Colour temperature white
Class of protection against electric shock I
IP class 54
Minimum distance from the illuminated object 0,5m
Ambient temperature range to which the product can be exposed -20÷35
Place of assembly wall mounted
Connection type Bolt terminal block
Range of sections of wires used [mm2] 1
Fixture lighting direction up and down
Sensor type PIR
Sensor-operation time [second-minute] 10-10
sensor working angle [°] H120
Sensor range[m] max 6
Movement detection no
Illumination-level setpoint by which the sensor detects movement [lx] 0-1000
Luminous efficiency of the lamp [lm/W] 49
Number of modules 2
Useful luminous flux of the light source Φuse [lm] 360
Useful luminous flux of the light source Φuse [lm] in sphere (360°)
Additional information Containing product (CP)
Shape other
Producent
Kanlux S.A.
ul. Objazdowa 1-3
41-922 Radzionków
Polska kanlux@kanlux.com www.kanlux.com

Materials

Specification
Family card PDF, Size: 604.9 KB
Technical card PDF, Size: 1022.49 KB
Support material PDF, Size: 3.66 MB
Handling and installation
User manual PDF, Size: 1.78 MB
Approvals and certificates
Warranty Statement PDF, Size: 134.71 KB
