AMPLINE 4LED 1-150-W

AMPLINE 4LED 1-150-W Kanlux
Miniatura AMPLINE 4LED 1-150-W - KANLUX Miniatura AMPLINE 4LED 1-150-W - KANLUX Miniatura AMPLINE 4LED 1-150-W - KANLUX Miniatura aranżacji AMPLINE 4LED 1-150-W Miniatura aranżacji AMPLINE 4LED 1-150-W Miniatura schematu AMPLINE 4LED 1-150-W

T8 LED tube linear fittings AMPLINE 4LED 150cm natynkowa

AMPLINE 4LED 1-150-W

Product code: 38035 logo KANLUX

An economical solution with versatile applications. The ability to connect in lines, modify the version, and its low price make this solution ideal for budget-friendly projects, such as shops, workshops, or industrial halls. Complemented with T8 LED fluorescent lamps from Kanlux, this solution allows for flexible selection of light output and color temperature depending on your needs and achieves excellent lighting parameters. Each luminaire allows individual modules to be connected in a line. An individual layout with versions for one and two fluorescent lamps allows the system to be adapted to the individual preferences of the user in accordance with the project requirements.

Product presentation
Rated voltage [V] 220-240 AC
Maximum power [W] 1 x max 24
Light source T8 LED
Cap G13
IP class 20
Colour white
Scroll down to the full specification
Ask a question
Go to dictionary

Do you want to maintain consistency?

See products from the same series
logo Kanlux Factory
AMPLINE 4LED 2-150-W - KANLUX AMPLINE 4LED 2-150-W - KANLUX
T8 LED tube linear fittings AMPLINE 4LED 150cm natynkowa AMPLINE 4LED 2-150-W Product code: 38036

Specification

General description
Warranty [years] 2
EAN13 5905339380357
Colour white
Enclosure material steel
Weight and dimensions
Height [mm] 68
Width [mm] 100
Length [mm] 1528
Weight 2302g
Sales unit piece
Outer box 1
Technical data
Rated voltage [V] 220-240 AC
Rated frequency [Hz] 50
Shade type louvre
Show more ▾
Colour white
Maximum power [W] 1 x max 24
Light source T8 LED
Light source included no
Cap G13
Class of protection against electric shock I
IP class 20
Ambient temperature range to which the product can be exposed 5÷25
Place of assembly ceiling mounted
Connection type Self-clamping block
Range of sections of wires used [mm2] 1,5-2,5
Power supply of T8 LED fluorescent lamps Unilateral
Fixture lighting direction down
Minimum distance from the illuminated object 0,5m
Replaceable light source yes
Producent
Kanlux S.A.
ul. Objazdowa 1-3
41-922 Radzionków
Polska kanlux@kanlux.com www.kanlux.com

Materials

Specification
Family card PDF, Size: 470.21 KB
Technical card PDF, Size: 941.89 KB
Support material PDF, Size: 2.97 MB
Handling and installation
User manual PDF, Size: 1.79 MB
Approvals and certificates
Declaration of Conformity PDF, Size: 804.26 KB

Before downloading the materials made available through this website in order to use them for further marketing or commercial purposes, please contact the Kanlux SA headquarters by sending an inquiry to kanlux@kanlux.pl concerning the conditions under which you will be able to use the Kanlux SA trademark or Kanlux SA materials protected by copyright. The use of materials downloaded from this website without our consent is illegal and violates our rights.

OPRAWA DO T8LED AMPLINE 4LED 1-150-W
