HB PRIME B 200W NW

HB PRIME B 200W NW Kanlux
Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura HB PRIME B 200W NW - KANLUX Miniatura schematu HB PRIME B 200W NW

High-bay LED light fitting HB PRIME B

HB PRIME B 200W NW

Product code: 45810 logo KANLUX

HB PRIME B is a next-generation high bay luminaire and the first in our range to achieve a luminous efficacy of 210 lm/W, meeting Energy Efficiency Class B standards. Thanks to selectable power settings of 200W / 160W / 120W, the fitting can be easily adapted to the size and requirements of the illuminated area, while maintaining high performance and application flexibility. HB PRIME B provides a neutral white light colour temperature of 4000K and a wide 90° beam angle, ensuring uniform illumination across large spaces. With an IP65 rating and a 50,000-hour lifetime, HB PRIME B is ideally suited for demanding industrial and warehouse environments.

Rated voltage [V] 220-240 AC
Maximum power [W] 200 / 160 / 120
Luminous flux of the light fitting [lm] 37000 / 29600 / 22200
Service life [h] 50000
Colour temperature [K] 4000
IP class 65
Scroll down to the full specification
Ask a question
Go to dictionary

Specification

General description
EAN13 5905339901101
Colour black
Enclosure material aluminum alloy
Protective glass material PC
Weight and dimensions
Height [mm] 115
Diameter [mm] 320
Weight 1896g
Sales unit piece
Outer box 1
Additional features
  • 5 years Warranty under the terms of the warranty statement, available on our website
Technical data
Rated voltage [V] 220-240 AC
Rated frequency [Hz] 50
Show more ▾
Colour black
Maximum power [W] 200 / 160 / 120
Integrated LED light source
Luminous flux of the light fitting [lm] 37000 / 29600 / 22200
Lighting angle [°] 90
Number of on/off cycles ≥50000
Service life [h] 50000
Colour temperature [K] 4000
Colour uniformity [SDCM] 6
Colour-rendering index Ra 70
Diode type LED SMD
Compatible with a dimmer no
Colour temperature white
Class of protection against electric shock I
IP class 65
Ambient temperature range to which the product can be exposed -20÷40
Place of assembly for suspension on the ceiling,ceiling mounted
IK class 08
Connection type Free cable ends
Wire type H05RN-F
Wire length [m] 0.27
Wire diameter [mm²] 1
Minimum distance from the illuminated object 1m
Number of modules 1
Useful luminous flux of the light source Φuse [lm] 40000
Useful luminous flux of the light source Φuse [lm] in wide cone (120°)
Mercury content no
Shape round
Producent
Kanlux S.A.
ul. Objazdowa 1-3
41-922 Radzionków
Polska kanlux@kanlux.com www.kanlux.com

Materials

Specification
Family card PDF, Size: 204.01 KB
Technical card PDF, Size: 48.66 KB
Handling and installation
User manual PDF, Size: 1.41 MB
Approvals and certificates
Declaration of Conformity PDF, Size: 811.7 KB
